SPECIFICATIONS

Brand Name: GZLOZONE

Hign-concerned Chemical: None

Maximum Power Per Channel: 15W

Origin: Mainland China

Package: Yes

Channels: 2 (2.0)

Certification: CE

Model Number: 5Z3P+6N8P+300B

Now the sound amplifier is popular with 300B amplifier by music lovers, 300B power amplifier sound transparent, thin, high stress analysis, sound natural and beautiful, some people think that listening to the addictive, so many people want to own it at home. Due to the 300B has been very expensive price, 300B commodity machine of course expensive too

Machine parameters:

Input voltage: 110V/220v 50Hz or 60Hz

Input selection: stereo dual channel

Rated output power: 8W+8W

The whole machine frequency response: 25Hz ~ 32kHz

Harmonic distortion: 1% (1W 1KHz)

Signal to noise ratio: 88dB/mw

Input sensitivity: 500mV

Input impedance: 100K

Output impedance: 8ohm

Residual noise: <3.5mV

Machine dimension (W * D * H): 38mm * 230mm * 180mm

Use vacuum tube: 6N8P * 2pcs, 300B * 2pcs, 5Z3P * 1pcs

Net weight: 14kg

Total power consumption: 180W

Technical parameters:

105*60 H 14 chip power transformer primary group 110V, can be used in parallel 110V, the two group of 110V series after the use of 220V, the output of the transformer 76*40 Z11 0.35 annealed sheet of three clip, inductance 66*32 Z11 0.35 Annealed sheet 6H 0.25A above all transformers Oxygen free copper wire winding
